Posted by on Dec 16 2013 in • I've often heard that a barrier to giving VMware's ESXi a try is the burden of figuring out how to inject a driver/VIB (vSphere Installation Bundle) file into the installer ISO file. The big OEMs do it, like HP and IBM, but the home lab enthusiast may not really feel like learning, nevermind the syntax. With the recent compared with 5.1, it seemed like a big problem to many. Turns out it isn't that big a deal, once you locate the fine work by Andreas Peetz () over on his site, using his GUI utility called * (see article end below, for updated info). In this step-by-step walkthrough supplemented by a video, I add ASMedia SATA, Realtek network, and LSI RAID monitoring support.

Quickly, simply, easily. There are many ways to add driver bundles, but this article will focus on an actual example procedure I created for my own home lab. My build has the motherboard from 2011. It has Realtek 8111 based NICs on the motherboard that worked great on ESXi 5.1, but ceased being recognized, when it came time for the ESXi 5.5 installer to see those devices. This gave me the dreaded 'No network adapters have been detected' message discuss by other Realktek owners.

Apr 23, 2015 Pretty basic question (I guess): I am trying to create a new VM server 2012r2 under ESXI 5.5 (build 2068190). At install Windows setup complains about a.

So instead of merely adding a fully support NIC like the, why not just inject this driver, along with any other needed drivers, right into the install ISO? That way, when I create the bootable USB flash drive using, I've now have the ISO to create that install source that also becomes the install target, with full support for all my devices. No SSH or VIB install commands to remember. Turns out the AHCI SATA ports on this motherboard by ASMedia also aren't seen by the ESXi 5.5, even though they worked fine on ESXi 5.1. This is described by Andreas in his recent post. Then there's my LSI 9265-8i RAID controller, which was never fully functional out of the box, requiring a VIB to get proper healthy monitoring going under all ESXi 5.x versions, described.

So the next hurtle was how to inject all 3 VIBs into the same ISO, given there is currently no multi-selection ability in the ESXi-Customizer VIB Browse button. Here's the workaround I developed, where you create a custom ISO by adding the first VIB, then repeat with the second, using the new bigger ISO as the source for that second injection.

Rinse, repeat. Details here. 1) the latest ESXi-Customizer I put the ESXi-Customizer-v2.7.1.exe into my C: VIBs folder. I then also took all 3 of my VIBs: (right-click, select 'Save As' to download) (filename is sata-xahci-1.10-1.x86_64.vib) for SATA support on many popular motherboards, described. (right-click, select 'Save As' to download) (filename is VMware_bootbank_net-r8168_8.013.00-3vmw.510.0.0.799733.vib) for networking adapter support, described.

(right-click, select 'Save As' to download) needs the Certified LSI SMIS VIB for RAID health, described. I used the ESXi SMIS VIB file for my exact LSI 9265-8i RAID controller.

Once downloaded, you'll need to extract the zip to locate the VIB within the extract to directory. Download Free Mcintosh Mx151 Manual High School on this page. And put them into the same C: VIBs directory, where I also put a copy of the original ESXi 5.5 installer called. By Andreas Peetz on Dec 11 2013 by Andreas Peetz on Nov 04 2013 by Paul Braren Sep 10 2013 by Paul Braren Sep 24 2013 Andreas Peetz has now published a very relevant article today: where he explains the following key info: Although ESXi-Customizer-PS makes the use of ImageBuilder much easier it is not as easy as ESXi-Customizer, because it does not provide a GUI, but needs to run in a Powershell/PowerCLI console. This is the main reason why ESXi-Customizer is so popular today and will probably remain popular for quite a while. The most requested feature of ESXi-Customizer is the ability to add multiple VIB files in one run.

I have not and will not implement that, but there are workarounds available: • Run ESXi-Customizer multiple times adding one VIB file per run and using the output ISO of one run as input for the next run. • Add all VIB files to one Offline Bundle (using vib2zip.cmd) and add this Offline Bundle instead of the individual VIB files.

Some Kind Of Wonderful Ost Rar Download there. Or just use ESXi-Customizer-PS with this Offline Bundle! Well, Andreas isn't kidding, this article has been viewed well over 500 times in these past few weeks, with the video at 340 views. It's not surprising, given the GUI makes adding 3 VIBs into one ISO so easy, with no command line stuff to copy and paste or memorize. So will I be changing my ESXi 5.5 install guides?

Probably not until a new GUI is developed by Andreas. Here's what Andreas says about that: I am aware that the legacy ESXi-Customizer tool is still very popular, because it offers a very clear and easy-to-use GUI that even ESXi beginners can work with.

In contrast the ESXi-Customizer-PS Powershell script looks intimidating (at least at first glance), because it requires you to enter a command line with lots of possible options. This is why I will work on improving the usability of ESXi-Customizer-PS and also adding some sort of GUI to it.In the meantime I will continue to support the legacy ESXi-Customizer tool, so - no worries - it will not go away completely soon! Frankly, for ESXi 5.5, no hurry really, I have my Realtek, ASM1062, and LSI working, so this may not be something I'll need to incorporate into my own home lab build process about until ESXi 6(?) is released, typically announced at VMworld in late August, with download availability in September.

So for the major refresh of that I'm working on now, I'll incorporate the new SSO-problem-free, and the 3 driver VIB install technique I used for the above article. By the way, this time around, the lab build procedure is under an hour, and the steps have actually been typed up as well, to be in an easy-to-use checklist format. Disclaimer Emphasis is on home test labs, not production environments. No free technical support is implied or promised, and all best-effort advice volunteered by the author or commenters are on a use-at-your-own risk basis.
